Jaw Coupling

Name: Jaw Coupling
Brand: SUPER MECH INDUSTRIES
Price: 170 INR
Availability: InStock

Price 170 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Jaw Coupling Specification

Connection
Clamp/Set screw

Torque
40 Nm

Head Code
Standard

Sealing
No sealing, open structure

Bore
Pilot bore, can be customized

Max. Speed
8500 RPM

Material
Cast Iron/Aluminium/Steel

Structure
Flexible jaw coupling with elastomer spider

Standard
DIN/ISO

Inner Diameter
12 mm (customizable)

Outer Diameter
56 mm

Application
Power transmission in mechanical equipment, pumps, and compressors

Surface Treatment
Black oxide finish

Technique
Precision machining

Shape
Jaw-shaped coupling with curved profile

Jaw Coupling Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
20 Pieces Per Day

Delivery Time
3 Days

About Jaw Coupling

We as a prime manufacturer, exporter and supplier are occupied with offering premium quality Jaw Coupling that ingests stun loads and damps little adequacy vibration. It is generally utilized as a part of different industry and is designed utilizing the best quality fundamental materials under the supervision of our talented experts. We offer this predominant quality Jaw Coupling at industry driving costs. The offered coupling is exceedingly valued by our customers for Features like strength, dimensional exactness, reduced configuration and consumption resistance.

Features:

Dimensional exactness
High elasticity
Consumption safe completion
Vigorous development

Specification

Features	Easy to fit
Application	Industrial
Size	1/2 inch
Material	GI

Reliable Performance in Demanding Environments

Designed to withstand harsh operational conditions, this jaw coupling operates efficiently in temperatures ranging from -40C to 100C. Its corrosion-resistant black oxide finish and robust material construction safeguard against environmental wear, making it a long-lasting choice for diverse industrial settings.

Exceptional Flexibility and Customization

This coupling combines precision engineering and flexibility. With a customizable pilot bore (standard inner diameter 12 mm, outer diameter 56 mm), and choice of connection methods (clamp/set screw), it adapts to specific equipment requirements. Its elastomer spider compensates for small misalignments, minimizing stress on connected components.

Optimized for Power Transmission Applications

Engineered to transmit up to 40 Nm torque at speeds up to 8500 RPM, this jaw coupling is ideal for pumps, compressors, and mechanical equipment. The smooth finish and low-maintenance design ensure a reliable operation, reducing downtime and enhancing productivity in power transmission systems.

FAQs of Jaw Coupling:

Q: How does the jaw coupling accommodate misalignments in mechanical systems?

A: The flexible elastomer spider in the jaw coupling allows it to compensate for axial misalignments up to 0.1 mm and angular misalignments up to 1, ensuring smooth operation and reducing wear on machinery components.

Q: What benefits does the polyurethane elastomer provide in this coupling?

A: Polyurethane elastomer, rated at 80A Shore hardness, delivers excellent vibration damping, minimizes noise, and extends the service life of the coupling by absorbing shock, making it ideal for demanding power transmission applications.

Q: When should this jaw coupling be used in power transmission systems?

A: This jaw coupling is recommended for use in equipment such as pumps, compressors, and other mechanical systems where excellent vibration damping, moderate misalignment compensation, and reliable torque transmission up to 40 Nm are essential.

Q: What is the process for customizing the bore of the coupling?

A: The pilot bore is standard but can be customized according to your specific shaft size requirements. As a manufacturer, exporter, and supplier, we offer precision machining to adjust the inner diameter based on your application needs.

Q: Where is this jaw coupling typically installed?

A: It is commonly installed in industrial environments, particularly in India and exported globally, for use in machines that require robust and flexible shaft connections, particularly where corrosion resistance and high rotational speeds are necessary.

Q: How does the black oxide surface treatment enhance the couplings performance?

A: The black oxide finish provides superior corrosion resistance, protects against moisture and rust, and maintains the smooth surface of the coupling, contributing to its long-term reliability.

Q: What maintenance is required for this jaw coupling?

A: Thanks to its rugged elastomer and precision-machined components, this jaw coupling requires minimal maintenance, typically only periodic inspection for wear or misalignment, ensuring efficient and reliable operation over time.
